• INPUTS:
• Line: 10kohm input impedance; 175mV rms sensitivity (for 1.22V output)
• Mic: 10kohm input impedance unbalanced; 3mV rms sensitivity (for 1.22V output); 85mV rms max input
• Phantom power: +15V
• Phono: 47kohm input impedance; 1.4mV rms sensitivity @ 1 KHz (for 1.22V output)
• OUTPUTS:
• Line: 9V rms max
• Headphone Amp: 0.5 watt into 47ohm
• Distortion: less than 0.01%
• SIGNAL TO NOISE RATIOS* (vs. maximum output):
• Line: Better than 96 dB
• Mic: Better than 78 dB
• Phono: Better than 87 dB
• *JIS - weighted
• FREQUENCY RESPONSE:
• Line: 20 Hz- 22k Hz ±0.5 dB
• Line: 20 Hz- 20k Hz ±0.5 dB
• Phono:±1 dB except for controlled attenuation of -3 dB @ 20 Hz to reduce rumble and feedback
• EQUALIZER:
• Bass: +/-6,12dB
• Low Middle: +/-6,12dB
• Middle: +/-6,12dB
• Treble: +/-6,12dB
• POWER CONSUMPTION:
• 21.6 Watt typical
• 28.8 Watt with full headphone output
